Our Model 210 Two-Drum Surface Winder: Designed to Handle Everything from Paperboard to Nonwovens

At Catbridge Machinery, we pride ourselves on delivering high-performance converting machinery that sets industry standards. Today we’re going to dive into a fan favorite, the Model 210 Two-Drum Surface Winder, the epitomize of efficiency and precision. Designed to handle a wide array of materials, from heavy paperboard to ultralight nonwovens, this machine is perfect for both standard and challenging slitting tasks.

Versatility in Material Handling

The Model 210 Two-Drum Surface Winder stands out for its versatility. It accommodates a range of materials, including heavy paperboard and ultralight nonwovens, making it an essential tool for industries that demand precision and repeatability in their converting processes. Whether dealing with robust packaging materials or delicate nonwovens, the Model 210 ensures consistent, high-quality output every time.

Advanced Specifications

Our commitment to innovation is reflected in the impressive specifications of the Model 210:

• Rewind Diameter: Up to 60 inches (1524 mm)
• Web Width: Up to 84 inches + (2137 mm +)
• Web Speed: Up to 3500 feet per minute (1067 meters per minute)
• Minimum Slit Width: 2 inches (51 mm)

These specifications ensure that the Model 210 can meet the demands of high-speed, high-volume operations, delivering exceptional performance across various applications.

Standard and Optional Features

The Model 210 comes equipped with an array of standard features designed to enhance its functionality:

• Overhead Web Path: Ensures a clear and streamlined path for the web.
• Shear Slitting: Provides clean and precise cuts.
• Programmable Profile Drum Torque: Allows customization of drum torque for optimal performance.
• Pneumatic Riding Roll: Enhances tension control.
• Web Threading Assist: Facilitates easy threading of the web.
• Shafted Rewind: Ensures stable and consistent rewinding.
• Roll Ejector: Simplifies the removal of finished rolls.
• CBM-1 Control System: Features a user-friendly interface for operations, maintenance, and safety.
• Safety PLC and Devices: Includes fencing and sensors for enhanced safety.

For businesses seeking additional capabilities, the Model 210 offers optional features such as:

• Splice Table, Two-Up Assembly, Score Slitting, Automatic Knife Positioning, Trim System, Dust Collection System, Single or Dual Bowed Rolls, Laser Core-Placement Assist, Shaftless Rewinding, Table or Freestanding Roll Discharge Table

These options allow for further customization, ensuring the machine can be tailored to specific operational needs.

Common Applications

The versatility of the Model 210 is highlighted by its suitability for a diverse range of applications. It is ideal for airlaid nonwovens used in various disposable products and excels in handling both coated and uncoated boards for packaging and industrial uses.

The winder is also effective for foil, whether supported or unsupported, used in packaging and insulation. It is perfect for label stock and meltblown nonwovens, crucial in filtration and insulation products.

Additionally, it handles metallized papers for decorative and packaging applications, paper to foil laminations for packaging materials, and various types of papers, both coated and uncoated, for printing and packaging.

Furthermore, the Model 210 is suitable for spunbond nonwovens used in hygiene products and geotextiles, thermal transfer papers used in printing, and tissue products for hygiene and packaging.

This broad range of applications underscores the Model 210’s flexibility and effectiveness in different industrial contexts.

Why Choose Catbridge Machinery?

Catbridge Machinery stands out in the converting machinery industry due to our unwavering commitment to innovation, precision, and customer satisfaction. Our state-of-the-art facility and dedicated team of professionals ensure that every piece of equipment meets the highest standards of performance and reliability. With a global presence, we provide comprehensive support, from startup assistance to remote servicing, ensuring our clients can maintain peak productivity and quality.

The Model 210 Two-Drum Surface Winder by Catbridge Machinery embodies the perfect blend of efficiency, precision, and versatility. With its advanced features and wide range of applications, this machine is an invaluable asset for industries looking to enhance their converting processes.

If you have any questions or need further information, don’t hesitate to contact us. Our team of experts is ready to assist you with all your converting machinery needs.
